PVC-B - Adjustable Proportioning Valve + Distribution Block PV4A - GM Disc/Disc Proportioning Valve - Aluminum
Our Price: $70.00
Our Price: $65.00
PVC-B - Adjustable Proportioning Valve + Distribution Block PV4A - GM Disc/Disc Proportioning Valve - Aluminum

Adjustable proportioning valve and distribution block all in one. Features a rotary adjustment to regulate rear brake pressure and help maintain correct brake bias between front and rear. Distribution block connects to master cylinder and distributes brake fluid to all four wheels. Includes five stainless steel fittings for 3/16" brake line, brake

  • Light switch and wiring pigtail included
  • Also available in Chrome (PVCB-C)

FITMENT

Applications coming soon!

SPECS

Part Number
PVC-B
UPC
635648180069
Orientation
Adjustment Style
Knob Adjustable
Inlet Quantity
(2) 3/8"-24 Female Inverted Flare
Outlet Quantity
(3) 3/8"-24 Female Inverted Flare
Finish
Black Anodized
Material
Aluminum
quantity
1
Weight
9x6x2
Box Size
2
Notes
Minimum Pressure 100 PSI, Maximum Pressure 3,000, PSI Presure Reduction 57%. Includes pressure switch that can be used to activate brake lights. Block measures 4 in. long, 1 in. wide, and 3 9/16 in. tall with the adjustment knob in the fully extended
GM Universal Combination Valve Disc/Disc Aluminum; Exact Copy of Original

  • (2) 3/8-24" ports for the front brakes
  • (1) 9/16-18" port for the rear brakes
  • Dash warning light connector
  • This is an universal valve and may not be an O.E.M Replacement valve
  • Please note fitting sizes for plumbing before purchasing

MBM also offers the PVTool and PVP dash warning light connector sold seperately.

FITMENT

Applications coming soon!

SPECS

Part Number
PV4A
UPC
635648179971
Orientation
Disc/Disc
Adjustment Style
Fixed
Inlet Quantity
(1) 1/2"-20 (1)7/16"-24
Outlet Quantity
(2) 3/8"-24 (1) 9/16"-18
Finish
Aluminum
Material
Aluminum
quantity
1
Weight
9x6x2
Box Size
2
Notes

Designed to be used in stock configuration on vehicles with disc/drum brakes. Recommended when large-port GM master cylinder is on the firewall. An alternative plumbing

PV2A - GM Disc/Drum Proportioning Valve - Aluminum PVC-C - Adjustable Proportioning Valve + Distribution Block 1
Our Price: $65.00
Our Price: $75.00
PV2A - GM Disc/Drum Proportioning Valve - Aluminum PVC-C - Adjustable Proportioning Valve + Distribution Block 1

GM Universal Combination Valve Disc/Drum Aluminum; Exact Copy of Original

  • Part of MBM's Proline Series
  • Aluminum Wont Rust!
  • (2) 3/8-24" ports for the front brakes
  • (1) 9/16-18" port for the rear brakes
  • Dash warning light connector

MBM also offers the PVTool and PVP dash warning light connector sold seperately.

FITMENT
Applications coming soon!

SPECS
Part Number

PV2A
UPC
635648179940
Orientation
Disc/Drum
Adjustment Style
Fixed
Inlet Quantity
(1) 1/2"-20 (1)7/16"-24
Outlet Quantity
(2) 3/8"-24 (1) 9/16"-18
Finish
Aluminum
Material
Aluminum
quantity
1
Weight
9x6x2
Box Size
2
Notes
Designed to be used in stock configuration on vehicles with disc/drum brakes. Recommended when large-port GM master cylinder is on the firewall. An alternative plumbing

Adjustable proportioning valve and distribution block all in one. Features a rotary adjustment to regulate rear brake pressure and help maintain correct brake bias between front and rear. Distribution block connects to master cylinder and distributes brake fluid to all four wheels. Includes five stainless steel fittings for 3/16" brake line, brake

  • Light switch and wiring pigtail included
  • Also available in black (PVCB-B)

FITMENT

Applications coming soon!

SPECS

Part Number
PVC-C
UPC
635648180076
Orientation
Adjustment Style
Knob Adjustable
Inlet Quantity
(2) 3/8"-24 Female Inverted Flare
Outlet Quantity
(3) 3/8"-24 Female Inverted Flare
Finish
Chrome
Material
Aluminum
quantity
1
Weight
9x6x2
Box Size
2
Notes
Minimum Pressure 100 PSI, Maximum Pressure 3,000, PSI Presure Reduction 57%. Includes pressure switch that can be used to activate brake lights. Block measures 4 in. long, 1 in. wide, and 3 9/16 in. tall with the adjustment knob in the fully extended
PV2C - GM Disc/Drum Proportioning Valve - Chrome APV-1 - Adjustable Proportioning Valve - Black
Our Price: $70.00
Our Price: $35.00
PV2C - GM Disc/Drum Proportioning Valve - Chrome APV-1 - Adjustable Proportioning Valve - Black

GM Universal Combination Valve Disc/Drum Chrome; Exact Copy of Original

  • (2) 3/8-24" ports for the front brakes
  • (1) 9/16-18" port for the rear brakes
  • Dash warning light connector
  • This is an universal valve and may not be an O.E.M Replacement valve
  • Please note fitting sizes for plumbing before purchasing

MBM also offers the PVTool and PVP dash warning light connector sold seperately

FITMENT
Applications:

1964 Buick Skylark
1965 Buick Skylark
1966 Buick Skylark
1967 Buick Skylark
1968 Buick Skylark
1969 Buick Skylark
1970 Buick Skylark
1971 Buick Skylark
1972 Buick Skylark
1964 Buick Special
1965 Buick Special
1966 Buick Special
1967 Buick Special
1968 Buick Special
1969 Buick Special
1967 Chevrolet Camaro
1968 Chevrolet Camaro
1969 Chevrolet Camaro
1964 Chevrolet Chevelle
1965 Chevrolet Chevelle
1966 Chevrolet Chevelle
1967 Chevrolet Chevelle
1968 Chevrolet Chevelle
1969 Chevrolet Chevelle
1970 Chevrolet Chevelle
1971 Chevrolet Chevelle
1972 Chevrolet Chevelle
1964 Chevrolet El Camino
1965 Chevrolet El Camino
1966 Chevrolet El Camino
1967 Chevrolet El Camino
1968 Chevrolet El Camino
1969 Chevrolet El Camino
1970 Chevrolet El Camino
1971 Chevrolet El Camino
1972 Chevrolet El Camino
1964 Chevrolet Malibu
1965 Chevrolet Malibu
1966 Chevrolet Malibu
1967 Chevrolet Malibu
1970 Chevrolet Monte Carlo
1971 Chevrolet Monte Carlo
1972 Chevrolet Monte Carlo
1964 Oldsmobile 442
1965 Oldsmobile 442
1966 Oldsmobile 442
1967 Oldsmobile 442
1968 Oldsmobile 442
1969 Oldsmobile 442
1970 Oldsmobile 442
1971 Oldsmobile 442
1964 Oldsmobile Cutlass
1965 Oldsmobile Cutlass
1966 Oldsmobile Cutlass
1967 Oldsmobile Cutlass
1968 Oldsmobile Cutlass
1969 Oldsmobile Cutlass
1970 Oldsmobile Cutlass
1971 Oldsmobile Cutlass
1972 Oldsmobile Cutlass
1964 Oldsmobile F85
1965 Oldsmobile F85
1966 Oldsmobile F85
1967 Oldsmobile F85
1968 Oldsmobile F85
1969 Oldsmobile F85
1970 Oldsmobile F85
1971 Oldsmobile F85
1972 Oldsmobile F85
1964 Oldsmobile Vista Cruiser
1965 Oldsmobile Vista Cruiser
1966 Oldsmobile Vista Cruiser
1967 Oldsmobile Vista Cruiser
1968 Oldsmobile Vista Cruiser
1969 Oldsmobile Vista Cruiser
1970 Oldsmobile Vista Cruiser
1971 Oldsmobile Vista Cruiser
1972 Oldsmobile Vista Cruiser
1967 Pontiac Firebird
1968 Pontiac Firebird
1969 Pontiac Firebird
1964 Pontiac GTO
1965 Pontiac GTO
1966 Pontiac GTO
1967 Pontiac GTO
1968 Pontiac GTO
1969 Pontiac GTO
1970 Pontiac GTO
1971 Pontiac GTO
1972 Pontiac GTO
1964 Pontiac Lemans
1965 Pontiac Lemans
1966 Pontiac Lemans
1967 Pontiac Lemans
1968 Pontiac Lemans
1969 Pontiac Lemans
1970 Pontiac Lemans
1971 Pontiac Lemans
1972 Pontiac Lemans
1964 Pontiac Tempest
1965 Pontiac Tempest
1966 Pontiac Tempest
1967 Pontiac Tempest
1968 Pontiac Tempest
1969 Pontiac Tempest
1970 Pontiac Tempest


SPECS

Part Number
PV2C
UPC
635648179957
Orientation
Disc/Drum
Adjustment Style
Fixed
Inlet Quantity
(1) 1/2"-20 (1)7/16"-24
Outlet Quantity
(2) 3/8"-24 (1) 9/16"-18
Finish
Chrome
Material
Aluminum
quantity
1
Weight
9x6x2
Box Size
2
Notes
Designed to be used in stock configuration on vehicles with disc/drum brakes. Recommended when large-port GM master cylinder is on the firewall. An alternative plumbing
    Universal design
  • Adjustable
  • Black finish
  • Maximum pressure regulation
  • 300 psi.
  • Inlet port of valve: 1/8 – 27 NPT
  • Standard adaptors: 3/8” – 24 for 3/16” line included
  • Mounting hole diameter: .250” (two)
  • Adjustable proportioning valves are essentially pressure reducing valves and are oftenutilized in disc/drum, disc/disc and drum/drum braking systems. The valve is used to controlfront-to-rear brake pressure bias and will work for all types of vehicles. Install this valvebetween the distribution block and the rear flex hose in the frontto rear rigid brake line.Always use tube wrenches to tighten fittings properly. Final settings of this valve will depend on your particular vehicle, and individual preference.
FITMENT
- Universal Fitment mostly used on Street Rods.

SPECS
Part Number
APV-1
UPC
635648180090
Orientation
Adjustment Style
Knob Adjustable
Inlet Quantity
(1) 3/8"-24 Female Inverted Flare
Outlet Quantity
(1) 3/8"-24 Female Inverted Flare
Finish
Black Anodized
Material
Aluminum
quantity
1
Weight
9x6x2
Box Size
1
Notes
Comes complete with (2) 3/8"-24 Female Inverted Flare Fittings
